Premium M2-M10 Self-Clinching Studs: High-Strength Fastening for Sheet Metal
Our M2-M10 Self-Clinching Studs, frequently referred to as Clinch Studs, provide an efficient and reliable way to add permanent threaded studs to thin metal plates. Unlike traditional welding, these clinch fasteners are installed using a simple press-in process. This ensures no heat-related distortion, smoke, or splatter, maintaining the integrity of the metal’s surface finish. Manufactured to industry standards like FH and FHS, our studs are the backbone of modern electronics chassis and telecommunications cabinetry.
As a professional self-clinching fastener factory, we utilize high-precision cold-heading technology to produce studs with exceptional dimensional accuracy and a robust clinching ring that guarantees maximum torque-out resistance.
- Clean Installation: Eliminates the need for costly and messy welding or tapping, saving significant assembly time.
- Superior Holding Power: The cold-flow process locks the metal sheet into the fastener’s undercut, providing incredible pull-out strength.
- Flush Surface Finish: The head sits perfectly flush with the metal sheet, allowing for a clean, professional aesthetic on external panels.
- Material Compatibility: We offer FHS series for stainless steel sheets and FHA series for lightweight aluminum components.
| Thread Size | Hole Size (+0.08) | Min. Sheet Thickness | Min. Dist. to Edge |
|---|---|---|---|
| M3 | 3.0 mm | 1.0 mm | 5.6 mm |
| M4 | 4.0 mm | 1.0 mm | 7.2 mm |
| M5 | 5.0 mm | 1.0 mm | 7.9 mm |
| M6 | 6.0 mm | 1.5 mm | 9.1 mm |
| M8 | 8.0 mm | 2.4 mm | 12.7 mm |
- Electronic Enclosures: Mounting PCBs, power supplies, and fan units inside server racks and PC cases.
- Automotive Electronics: Securing control modules and sensors in thin-walled aluminum housings.
- Medical Equipment: Providing hygienic, permanent threads in stainless steel diagnostic tools.
- Aerospace Hardware: Lightweight aluminum clinch studs for avionics panels.
A: FH is made from heat-treated carbon steel (for use in steel sheets), while FHS is made from 300 series stainless steel (for use in softer metal or stainless steel sheets).Q: Do I need a special machine for installation?
A: For best results, a standard clinching press (hydraulic or pneumatic) should be used to apply a steady, parallel force. Hammering is not recommended as it will damage the clinching ring.
Source M2-M10 Self-Clinching Studs from a Trusted Factory
Seeking bulk clinch studs with consistent hardness and competitive pricing? We support global wholesale and provide samples for testing. Contact us today for a free quote!
